Lakes Coastline Collection
Valmiera Quadrant
The Lakes Valmiera Quadrant is a cost effective solution with emphasis on design, quality and function. Pillarless glass side panels, sleek handles and a minimal frame form an exceptional quadrant enclosure that benefits from a manufacturers lifetime guarantee and AllClear coating as standard.
Suitable Applications:
Corner Shower Enclosures
Features:
Lifetime guarantee
Fully reversible
8mm toughened glass
Easy installation
Polished silver frame
2m frame
Wet room or tray installation
AllClear as standard
Technical Drawing
| Lakes Valmiera Offset Quadrant | (1 required) | ||||
| Product | Width (mm) | Height (mm) | Width Adjustment (mm) | Door Opening Size (mm) | Product Code |
| Lakes Valmiera Quadrant 800mm | 800 | 2000 | 765 – 795 | 390 | 1 x 8HR080 05 & 1 x 8HRDG |
| Lakes Valmiera Quadrant 900mm | 900 | 2000 | 865 – 895 | 550 | 1 x 8HR090 05 & 1 x 8HRDG |
| Lakes Valmiera Quadrant 1000mm | 1000 | 2000 | 965 – 995 | 550 | 1 x 8HR100 05 & 1 x 8HRDG |
| Lakes Valmiera Extension Profile | (Optional) | ||||
| Product | Width (mm) | Height (mm) | Width Adjustment (mm) | Door Opening Size (mm) | Product Code |
| Lakes Valmiera Extension Profile 15mm | 15 | 2000 | 8HLEP 05 |
